PRODUCT DESCRIPTION
Compact and Lightweight NDT Radiography Equipment for Industrial X-ray Testing with Innovative Design
Main introduction:
RD-1803 stands as a cutting-edge industrial X-ray machine embodying a breakthrough design concept. Characterized by its compact size, lightweight construction (generator weighs merely 12kg), and dependable durability, it features a rational internal layout and率先 (pioneers) the use of imported high-power components, complemented by a robust system protection function. Suitable for installation, maintenance, and non-destructive testing in tight spaces within power plants, chemical plants, aircraft manufacturing facilities, boiler pressure vessel production, and aluminum tube/sheet industries. This series includes directional (40±5° radiation angle) and circumferential (360°) models, with a maximum penetration capacity of 20mm for A3 steel.
Specialized Ceramic X-Ray Tube Manufacturing:
We are professional producers of ceramic X-ray tubes, capable of designing and manufacturing various specifications of X-ray ceramic tubes in accordance with customer needs.
Technical Advantages:
• Speed Regulation: Achieves gentle startup and low-speed positioning for precise operation.
• Magnetic Positioning System: Indicates crawler position and status through audible beep signals.
• Electrical Welding Immunity: Operates without interference from electric welding machines.
• Constant Voltage Control: Ensures uniform X-ray film density, resists low-energy fluctuations, conserves energy, and protects motors from overcurrent damage.
.
RD-1803TH the technical parameters
|
|
Project
|
RD-1803TH
|
|
input
|
Input power
|
Single-phase 50Hz AC 220± 10% V
|
|
|
Power supply capacity
|
No less than 2.0 KVA
|
|
output
|
X - ray tube voltage
|
50~ 180 KVp
|
|
|
X ray tube current
|
3mA
|
|
|
mA Stability degree
|
± 1%
|
|
Ray tube
|
Focal size
|
1.0× 2.0
|
|
|
X-ray irradiation range
|
360°
|
|
Ray generator
|
working pressure
Cooling mode
Insulation way
|
0.45MPa ~ 0.5Mpa
Anode ground connection radiator Strong wind cold
Gas insulation SF6
|
|
|
Size
weight (kg)
|
Φ210×590
|
|
|
|
12
|
|
Maximum penetration
|
Thickness steel A3(mm)
|
20 mm (5 min)
|
|
|
condition
|
focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5
|
|
|
sensitivity
|
superior 2%
|
|
controller
|
Size
weight
Circuit
|
325×270×180
< 9(kg)
Automatic control and protection
|
|
Environment
|
working temperature relative humidity
Altitude
|
-30°~ +40°
Not more than 85%
Not higher 1500m
|
|
methods
|
fully automatic 1:1 Work and rest,Longest continuous exposure time 5mins
|
