PRODUCT DESCRIPTION
Portable NDT X Ray Flaw Detector Welding Crack Detection Xray Machine Testing Equipment Company introduction:
We have been focusing on the innovation and development of industrial X-ray equipment for more than 30 years. After many years of development, we successfully developed the RD28/35 series of portable X-ray machines, which are small in size, light in weight and have a low failure rate. After years of development, the RD28/35 series has become the main non-destructive testing equipment for natural gas and oil pipelines, power systems, military shipyards, nuclear power plants, chemicals, boiler pressure vessel inspections, and valve manufacturing industries. In 2016, after years of research and development, our company independently developed the high-end model 300LG, which can work continuously for 99 minutes (the continuous working time of domestic peer equipment is five minutes) and has a penetration of more than 80MM. Subsequently, this model has become the main product in the field of high-end inspections such as domestic oil pipeline inspections, and has a market share of more than 70% in the domestic natural gas pipeline ray inspection equipment market segment. In 2021, after several years of arduous research and development, our company broke through the technical barriers of overseas companies and successfully developed high-frequency portable X-ray equipment with completely independent intellectual property rights, becoming the first company in the domestic industry to master the core technology of portable high-frequency; in 2022, we developed the ultra-small equipment T200 series, which is the main torch detection equipment for the Hangzhou Asian Games. In the same year, the company entered the nuclear power and military industry; in 2024, we developed the Hangshe 1.0 digital imaging system, phased array detection, ultrasonic detection and magnetic particle detection products; the Fuyang Dayuan factory was completed at the end of June. In April 2025, Hivi won the Fuyang Lingqiao Plot No. 6, and is expected to start construction in September and be officially completed and put into production in 2027.
RD-1803T the technical parameters
|
|
Project
|
RD-1803T
|
|
input
|
Input power
|
Single-phase 50Hz AC 220± 10% V
|
|
|
Power supply capacity
|
No less than 2.0 KVA
|
|
output
|
X - ray tube voltage
|
50~ 180 KVp
|
|
|
X ray tube current
|
3mA
|
|
|
mA Stability degree
|
± 1%
|
|
Ray tube
|
Focal size
|
0.9× 0.9
|
|
|
X-ray irradiation range
|
45±5°
|
|
Ray generator
|
working pressure
Cooling mode
Insulation way
|
0.45MPa ~ 0.5Mpa
Anode ground connection radiator Strong wind cold
Gas insulation SF6
|
|
|
Size
weight (kg)
|
Φ210×580
|
|
|
|
12
|
|
Maximum penetration
|
Thickness steel A3(mm)
|
25 mm (5 min)
|
|
|
condition
|
focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5
|
|
|
sensitivity
|
superior 2%
|
|
controller
|
Size
weight
Circuit
|
325×270×180
< 9(kg)
Automatic control and protection
|
|
Environment
|
working temperature relative humidity
Altitude
|
-30°~ +40°
Not more than 85%
Not higher 1500m
|
|
methods
|
fully automatic 1:1 Work and rest,Longest continuous exposure time 5mins
|
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2. why should you buy from us not from other suppliers?
HANGZHOU HUIWEI NDT DEVICES CO.,LTD is a professional manufacturer specilizing in NDT equipment for 30 years long, integrating development and manufacturing in-house. and it is one of companies strong supported by country.
3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Escrow;
