Industrial X Ray Machine RD 3505 Portable Radiographic Device for Heavy Wall Steel Inspection and Structural Weld Flaw Detection

1 set
MOQ
17000-25000usd/set
Price
Industrial X Ray Machine RD 3505 Portable Radiographic Device for Heavy Wall Steel Inspection and Structural Weld Flaw Detection
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 12 Months
Usage: Spaceflight Industry, Welding Engineering Industry, Shipbuilding Industry Inspection
Power Supply: AC220V±10%
Application: Industrial Field
Function: Steel Defect,NDT Inspection Welding
Color: Stainless Steel,Silver Gray,blue And White
Max.penetration: 55mm(A3 STEEL)
Film Type: Any Kinds Of Industrial Film
Voltage: 170-350kv
Exposure Time: 15 Minutes
Name: NDT Industrial X-ray Machine
Tube Current: 5mA
Weight: 34kg
Focus Spot: 2.5*2.5
Generator Weight: 12kg
Basic Infomation
Place of Origin: ZHEJIANG, CHINA
Brand Name: HUIWEI
Certification: ISO 9001, CE
Model Number: RD-3505
Payment & Shipping Terms
Packaging Details: Standard export plywood package
Delivery Time: 15working days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 500sets within one month
Product Description

PRODUCT DESCRIPTION

The RD-3505 is our high-penetration portable X-ray flaw detector designed for heavy-wall industrial NDT applications. Delivering up to 55mm steel penetration at 350kV, this unit combines professional-grade radiographic performance with true field portability — making it the workhorse choice for chemical tank farms, large-diameter pipelines, and heavy structural weld inspection.





RD-3505 the technical parameters





Project

RD-3505

input

Input power

Single-phase  AC150-250V 50/60Hz

Power supply capacity

No less than 3.0 KVA

output

X - ray tube voltage

170~ 350 KVp

X ray tube current

5mA

mA Stability degree

± 1%

Ray tube

Focal size

2.5× 2.5

X-ray irradiation range

40±5°

Ray generator

working pressure

Cooling mode

Insulation way

0.35MPa ~ 0.5Mpa

Anode ground connection radiator Strong wind cold

Gas insulation SF6

Size

weight (kg)

φ320×640

34

Maximum penetration

Thickness steel A3(mm)

55 mmFe(5 min)

condition

focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5



sensitivity

superior 2%

controller

Size

weight

Circuit

325×270×180

< 9(kg)

Automatic control and protection

Environment

working temperature relative humidity

Altitude

-30°~  +40°

Not more than 85%

Not higher 1500m

methods

fully automatic 4:1 Work and rest,Longest continuous exposure time 15mins



Typical Application Solutions

Solution 1: Chemical Spherical Tank Inspection

  • Recommended Model: RD-3505 (Directional)
  • Application: Double-wall single-image radiographic testing of spherical storage tanks
  • Why RD-3505: 55mm penetration handles thick-wall tank shells; 15min continuous exposure reduces tank entry time; portable design facilitates scaffolding-mounted operation

Solution 2: Large-Diameter Pipeline Weld Testing

  • Recommended Model: RD-3505TH (Circumferential)
  • Application: Circumferential weld inspection of large-diameter oil/gas/water pipelines
  • Why RD-3505TH: 360° panoramic beam covers full circumference in one exposure; 50mm penetration accommodates heavy-wall pipe; 2.5:1 duty cycle improves daily inspection footage

Solution 3: Heavy Structural Weld QC

  • Recommended Model: RD-3505 (Directional)
  • Application: Bridge steel structures, offshore platforms, heavy machinery welds
  • Why RD-3505: High voltage and strong penetration for thick structural steel; field-portable for on-site construction quality control
  •

    Quality & Service Commitment

    Quality Assurance

    • Every unit undergoes full performance testing before shipment
    • ISO 9001 quality management system certified
    • Work Safety Standardization Level 3 enterprise certified
    • Core components sourced from premium international suppliers


    After-Sales Service


    Service Item Details
    Warranty Period 12 months from date of delivery
    Technical Support Lifetime online/phone technical consultation
    Spare Parts Long-term supply of genuine spare parts
    Training Operator training & safety training available
    Response Time 24-hour response to technical inquiries



FAQ

1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

2. why should you buy from us not from other suppliers?
HANGZHOU HUIWEI NDT DEVICES CO.,LTD is a professional manufacturer specilizing in NDT equipment for 30 years long, integrating development and manufacturing in-house. and it is one of companies strong supported by country.

3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Escrow;
