RD-2505T 250KVp SF6 Gas Insulated Portable X Ray Flaw Detector 5mA 40mm Steel Penetration

Product Introduction

The RD-2505T Portable Industrial X-Ray Flaw Detector is developed and manufactured by Hangzhou Huiwei NDT Equipment Co., Ltd. It is an SF6 gas-insulated, portable radiographic testing system engineered for non-destructive testing (NDT) of welds, castings, pipelines and pressure vessels in field and confined-space applications. Delivering a 150–250 KVp X-ray output at 5mA tube current, the RD-2505T combines strong penetration (up to 40mm A3 steel) with a compact, mobile form factor.

The matched HW-001 intelligent controller uses a modular main circuit, duct-style heat dissipation and an industrial stepless knob for rapid, reliable parameter setting. The unit is fully compatible with global distributors and OEM/ODM demands.

Key Features

• SF6 gas-insulated X-ray generator with anode-grounded, forced air-cooled radiator
• 150–250 KVp continuously selectable tube voltage, 5mA tube current, ±1% stability
• 2.0×2.0mm focus and 45°±5° radiation angle for sharp radiographic images
• Up to 40mm A3 steel penetration (5 min exposure), image sensitivity better than 2%
• Fully automatic 2.5:1 work/rest cycle, longest continuous exposure 15 minutes
• HW-001 controller with industrial stepless knobs, LED status display and fault self-diagnostics
• Soft-start / slow-shutdown, automatic training mode and discharge self-voltage-reduction protection
• Safety-door interlock terminal and over-temperature protection for safe field operation

Technical Parameters

Radiographic test conditions: focal length 600mm, Agfa film, double-sided lead foil intensifying screen, developer temperature 22°C, film density ≥ 1.5.

Company Profile

Founded in 1993, Hangzhou Huiwei NDT Equipment Co., Ltd. is a national high-tech enterprise specializing in the R&D and manufacture of portable industrial X-ray flaw detectors. From a 12,000 m² base in Hangzhou, Zhejiang, we hold 31 patents and software copyrights and operate an R&D center with China Jiliang University.

Our equipment serves the oil & gas pipeline, boiler & pressure vessel, chemical and aerospace industries, and we have long-term partnerships with clients such as CNPC and Sinopec. HUIWEI is committed to becoming a leading international manufacturer of high-performance industrial radiography equipment.

Shipping Information

• Packaging: Standard export plywood case with shockproof foam, suitable for sea and air freight.
• Delivery Time: 7–15 working days after order confirmation (stock items ship faster).
• Shipping Terms: EXW / FOB / CIF available; shipping method (sea, air, express) can be arranged per customer requirement.
• Port: Shanghai / Ningbo, China.

After-Sales Service

• 12-month warranty on the X-ray generator and controller.
• Lifetime technical support and spare parts supply.
• English operation manual and online operation guidance provided.
• OEM/ODM customization (logo, model parameters, packaging) available.

Why Choose HUIWEI

• 30+ years of NDT manufacturing experience with in-house R&D and production.
• ISO 9001 and CE certified products.
• Factory-direct pricing and stable supply for global distributors.
• Overseas service engineers and prompt technical response.
