Portable Industrial Xray Machine for Advanced Non-Destructive Testing and Inspection in Industrial Applications RD-G300
Main introduction:
Utilizing high-frequency constant-voltage technology, it offers strong penetration capabilities and short exposure times. It employs a specially designed metal-ceramic tube core, ensuring excellent shock resistance and overall reliability. Capable of continuous operation with a 100% duty cycle, it significantly reduces operational time. The tube head weighs only 30 kg, making it extremely lightweight and portable. Featuring a built-in constant-voltage module, it operates efficiently on AC power sources ranging from 85– 264 V / 45–65 Hz with low power consumption; this makes it particularly well-suited for field operations when paired with portable generators or battery packs. With an IP65 protection rating and rugged metal cable connectors, it is built to withstand harsh working environments, operating within a temperature range of -10°C to +50°C. Fully compatible with digital imaging applications.
Features short delivery lead times and low maintenance costs.
Core Technology Highlights
1️⃣ High-Frequency Constant-Voltage Technology
Utilizing advanced high-frequency constant-voltage technology, the RD-G300D delivers strong penetration capabilities with short exposure times — significantly reducing operational time and improving inspection throughput compared to conventional power-frequency machines.
2️⃣ Metal-Ceramic Tube Core
Employs a specially designed metal-ceramic tube core, ensuring excellent shock resistance and outstanding overall reliability. Built to withstand the rigors of field operation and transportation.
3️⃣ 100% Duty Cycle — Continuous Operation
Capable of continuous operation with a 100% duty cycle — no mandatory rest cycles required. At 35°C with maximum kV and 3mA, the unit supports 30 minutes of continuous exposure — maximize your productivity on every job.
4️⃣ Ultra-Light & Highly Portable
The tube head weighs only 30 kg, making it extremely lightweight and portable. Featuring a built-in constant-voltage module, it operates efficiently on AC power sources ranging from 85 – 264 V / 45 – 65 Hzwith low power consumption.
5️⃣ IP65 Environmental Protection
With an IP65 protection rating and rugged metal cable connectors, the RD-G300D is built to withstand harsh working environments. Operating temperature range: -10°C to +50°C — works reliably in extreme conditions.
6️⃣ Digital Imaging Ready
Fully compatible with digital imaging applications — seamlessly integrates with DR/CR systems for instant digital radiography, eliminating film processing and accelerating inspection workflows.
Manufacturer — Hangzhou Huiwei NDT
Hangzhou Huiwei Non-destructive Testing Equipment Co., Ltd.
Est. 1993 | National Key High-tech Enterprise | Zhejiang "Specialized, Refined, Differential, Innovative" SME
Our High-Frequency Innovation Journey
- 2018 — Successfully independently developed G300D high-frequency DC industrial X-ray machine
- 2018 — Certified as National Key High-tech Enterprise
- 2024 — Launched Hangshe 1.0 Digital Imaging System Software
- 2025 — Completed 300kV industrial DR R&D and prototype
- 2026 — Developed Industrial CT 3D Digital Imaging System
FAQ
Q1. What certificates will be offered?
CE and ISO are certified for most products.
Always high quality is offered to avoid any defective products. Also, protective packaging is offered to avoid destroy during
delivery.
Q2. How about the lead time?
If no stocks, it takes 7 to 15 working days to manufacture after receiving the advance payment.
If in stock, 2-4 working days are possible. But it depends on the exact products and quantity.
Q3. What's the MOQ ?
(1). Normally, MOQ is 1 piece. The quantity is depending on the clients’ needs.
(2)According to customer order, the quantity still can be negotiated and we will product immeditaly if we dont have stock.
