Non destructive Testing Industrial NDT X Ray Weld Inspection Equipment

1 set
MOQ
40000usd/set
Price
Non destructive Testing Industrial NDT X Ray Weld Inspection Equipment
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 12 Months
Power Supply: AC220V±10%
Application: Industrial Field
Function: NDT Inspection Welding
Color: Stainless Steel,Silver Gray,blue And White
Max.penetration: 80mm(A3 STEEL)
Film Type: Any Kinds Of Industrial Film
Voltage: 30-300kv
Exposure Time: 30 Minutes
Tube Current: 1-3mA
Weight: 30kg
Focus Spot: 2.5*2.5
Generator Weight: 30kg
Operating Temperature: 0-40°C
Image Processing Software: Included
Frequency: 50/60Hz
Technology: X-ray Imaging
Type: Non-destructive Testing Equipment
Power Supply: AC/DC
Highlight:

Non destructive Testing X Ray Weld Inspection Equipment

,

Industrial X Ray Weld Inspection Equipment

,

NDT x ray radiography ndt
Basic Infomation
Place of Origin: ZHEJIANG, CHINA
Brand Name: HUIWEI
Certification: ISO 9001, CE
Model Number: RD-G300D
Payment & Shipping Terms
Packaging Details: Standard export plywood package
Delivery Time: 15working days
Payment Terms: L/C,T/T,Western Union,
Supply Ability: 500sets within one month
Product Description

           300kv High Voltage Range Mobile Digital X-ray Dr System For NDT Inspection Industry Flaw Detector Equipment RD-G300D


Main introduction:

Technical Background of RD Series X-ray Equipment
Leveraging high-frequency constant voltage technology, the system delivers robust penetration and ultra-short exposure times for efficient inspections. Its specially designed metal ceramic tube core enhances seismic resistance, ensuring reliable performance in rugged environments.

Featuring a 100% duty cycle for continuous operation, it eliminates downtime and maximizes productivity. The tube head’s ultra-lightweight design (only 30 kg) ensures effortless portability for on-site use.

Equipped with an integrated constant voltage module, the system operates on wide-range AC power (85-264V/45-65Hz) with low energy consumption, making it ideal for field applications powered by portable generators or batteries. With an IP65 protection rating and durable metal cable connectors, it withstands harsh conditions, including temperatures from -10°C to +50°C.

Fully compatible with DR (digital radiography) systems, the equipment offers rapid delivery and minimal maintenance costs, combining technical excellence with operational practicality.



RD-G300TechnicaParametersNon destructive Testing Industrial NDT X Ray Weld Inspection Equipment


Hangzhou Huiwei NDT Equipment Co., Ltd., founded in 1993, is a national key‑supported high‑tech enterprise specializing in R&D, production and sales of industrial X‑ray flaw detectors. Headquartered in Yuhang District, Hangzhou, its production base sits in Fuyang Fuchunwan New City.
Focusing on portable industrial X‑ray equipment, Huiwei has achieved multiple technical breakthroughs. It launched the RD‑300LG series in 2016 and pioneered X‑ray machine leasing services. The self‑developed G300 high‑frequency DC X‑ray series came out in 2018. The company has obtained qualifications including National High‑Tech Enterprise, Zhejiang Specialized‑Refined‑Differential‑Innovative SME, and Level‑3 Work Safety Standardization Enterprise, holding 25 authorized patents.
Our products serve petroleum & gas pipelines, pressure vessels, chemical, aerospace . Long‑term strategic cooperation has been built with CNPC, Sinopec and other major enterprises.
Adhering to the philosophy of “Pragmatic Innovation, Pursuit of Excellence”, Huiwei commits to advancing China’s NDT industry and aims to be an international leader of high‑performance industrial X‑ray equipment. With superior technology, quality products and full‑range services, we deliver solid commercial value for global customers. Let us join hands for shared future success.
Hangzhou Huiwei NDT Equipment Co., Ltd., founded in 1993, is a national key‑supported high‑tech enterprise specializing in R&D, production and sales of industrial X‑ray flaw detectors. Headquartered in Yuhang District, Hangzhou, its production base sits in Fuyang Fuchunwan New City.
Focusing on portable industrial X‑ray equipment, Huiwei has achieved multiple technical breakthroughs. It launched the RD‑300LG series in 2016 and pioneered X‑ray machine leasing services. The self‑developed G300 high‑frequency DC X‑ray series came out in 2018. The company has obtained qualifications including National High‑Tech Enterprise, Zhejiang Specialized‑Refined‑Differential‑Innovative SME, and Level‑3 Work Safety Standardization Enterprise, holding 25 authorized patents.
Our products serve petroleum & gas pipelines, pressure vessels, chemical, aerospace . Long‑term strategic cooperation has been built with CNPC, Sinopec and other major enterprises.
Adhering to the philosophy of “Pragmatic Innovation, Pursuit of Excellence”, Huiwei commits to advancing China’s NDT industry and aims to be an international leader of high‑performance industrial X‑ray equipment. With superior technology, quality products and full‑range services, we deliver solid commercial value for global customers. Let us join hands for shared future success.


Non destructive Testing Industrial NDT X Ray Weld Inspection Equipment

Non destructive Testing Industrial NDT X Ray Weld Inspection Equipment
